PRODUCTS

FIVE STAR TAM PANELS (with or without handles)

  • Penetrant Testing and Monitoring Panels (Polished or Grit)
  • Polished TAM Panels come with Chrome Polish on left side and Grit Blasted on right
  • Grit TAM Panels are Grit Blasted on both the left and right Side
  • Grit and Polished are manufactured from a 4x6 Stainless Steel Plate with 5 indications ranging from largest to smallest at specified and approved sizes per TAM 146040.
  • Certificate of Conformance comes with each and every Five Star TAM Panel
  • All Re-certifications are tested and done in-house  (Ask for Details)



FIVE STAR TWIN TESTING PANELS

  • Stainless Steel 4x6 Plate is sheared in half to create two "2x6" panels which are then nickel plated, grit blasted and cracked so that 5 indications are created on each TTP from largest to smallest based on the same standards and sizes as our Five Star TAM Panels
  • Meeting ASTM E-1417 as a comparison tool



COPPER PADS

  • Double-Layered replacement copper pads for magnetic particle equipment
  • Standard pads 5" x 7"
  • Other sizes available



FIVE STAR V-BLOCKS (Copper Pads Double-Layered)

  • Double-Layered copper braid over Neoprene pad
  • Reversible Pads
  • Designed to fit certain mag equipment



SPRING LOADED CONTACT CLAMP. Used for inspection bars and tubular assemblies connected by lugs or flexible cables to electrical terminals



FIVE STAR FLOURESCENT PENETRANT INSPECTION SYSTEMS 5S100 & 5S 100E

  • Standard FPI systems
  • Water washable 5S100 - dimensions 33" W x 130" L x 36" H
  • Emulsifiable 5S100E - dimensions 33" W x 146" L x 36" H



FIVE STAR CUSTOM EQUIPMENT. FPI systems built to your specifications

Other NDT PRODUCTS

  • Tri Con Spray Guns
  • Washability Panels
